Leica Disto X6 Laser Distance Meter
- Range up to 250 m
- Fast Start-up time
- Bright and clear 2.8” touchscreen
- DIST key on the side for even more intuitive measurements
- IP65 weatherproof
- Drop tested from 2 meters
- Trigger measurements with gestures
Compatibility:
Leica DISTO X3, X4, D5, D510, D810, X6, S910
Leica DISTO TA 360, FTA 360, FTA 360-S, DST 360, DST 360-X
Leica Lino P5, L2, L2G, L2P5, L2P5G, L6R, L6G
Leica Lino adapter TWIST 250, TWIST 360
Accuracy with favourable conditions | 1.0 mm / 1/16" |
Accuracy with unfavourable conditions | 2.0 mm / 1/8" |
Range with favourable conditions | 0.05 – 250 m / 0.07 – 820 ft |
Range with unfavourable conditions | 0.05 – 150 m / 0.07 – 500 ft |
Smallest unit displayed | 0.1 mm / 1/32 in |
X-Range Power Technology | Yes |
Laser | class 2, 635 nm, <1 mW |
Digital Pointfinder with 4-fold zoom | Yes |
Tilt measuring range* | 360° |
Tilt measuring tolerance | ± 0.2° |
ø laser point | at distances | 6 / 30 / 60 mm | 10 / 50 / 100 m |
Protection class | IP65 (dust tight and jet water protected) |
drop tested from 2 m height | |
Auto. laser switch off after | 90 s |
Auto. power switch off after | 180 s |
Memory | up to 300 reports |
Bluetooth® Smart | Bluetooth® v5.0 |
Range of Bluetooth® Smart | up to 10 m |
Battery durability (Li-Ion 2 000 mAh) | up to 4’000 measurements |
up to 8 hours operation time | |
Dimension (H x D x W) | 154 x 68 x 25 mm |
Weight (with batteries) | 230 g |
Temperature range storage | operation | -25 to 70 °C | -10 to 50 °C |
Brochures | |
---|---|
LG950909 - Brochure | Datasheets |
Leica Disto X6 Laser Distance Meter - Datasheet |
- Leica DISTO X6 laser distance meter
- Hand loop
- Pouch
- USB cable
- Safety instructions
- Calibration Certificate Silver
- Quick Start with QR code linking to online manual
- 3 Years warranty card
Brand: Leica Geosystems |
Code: LG950909
APN: 7640180531258 |
Supplier Code: 950909
Brand: Leica Geosystems |
Code: LG950909
APN: 7640180531258 |
Supplier Code: 950909
At a glance
- Range up to 250 m
- Fast Start-up time
- Bright and clear 2.8” touchscreen
- DIST key on the side for even more intuitive measurements
- IP65 weatherproof
- Drop tested from 2 meters
- Trigger measurements with gestures
