SECO Tri-Max Heavy Duty Elevating Tripod - 2.6m
$3,850.00
In Stock
- Seco Universal Tri-Max elevator tripod is ideal for laser scanners, total stations and laser level instruments.
- Instruments are attached to the top or bottom of the center column.
- The tripod can both elevate or lower instruments.
- Gear box controls lift and descent so the center column cannot free fall
- Maximum height: 2.6m
- Additional 1 meter section can add max height to 3.6m
- SECO’s Universal Tri-Max Elevator Tripod features a working height range of 4.10 ft (1.20 m) collapsed to 8.60 ft (2.62 m) extended with the center column at full height
- The center column independently lifts 1.00 meters
- A gear box controls lift and descent so the center column cannot free fall
- Additional 1 meter section may be added for a total recommended height of 10 ft (3 m) for instruments under 15 lb (6.80 kg)
- The 5/8 x 11 mounting head is removable and adjustable in azimuth direction
- Machined-aluminum elevator column and fiberglass legs makes for a robust and easy-to-use laser instrument tripod
- Applications include laser scanning and robotics
- Fiberglass Legs
- Stable for instruments up to 11.33 kg, under most conditions
- Weighs 13.20 kg
| Material | Fiberglass legs and aluminium elevator column |
| Tripod head | Flat |
| Base thread size | 5/8" x 11 |
| Clamp style | Dual screw clamps (top and bottom) |
| Max Height | 2.62m |
| Collapsed Height | 1.2m |
| Weight | 13.2kg |
| Datasheets | |
|---|---|
| SECO Tri-Max Heavy Duty Elevating Tripod - 2.6m - Datasheet |
Brand: Seco |
Code: SEC90558
APN: 9319499086879 |
Supplier Code: 90558
Brand: Seco |
Code: SEC90558
APN: 9319499086879 |
Supplier Code: 90558
At a glance
- Seco Universal Tri-Max elevator tripod is ideal for laser scanners, total stations and laser level instruments.
- Instruments are attached to the top or bottom of the center column.
- The tripod can both elevate or lower instruments.
- Gear box controls lift and descent so the center column cannot free fall
- Maximum height: 2.6m
- Additional 1 meter section can add max height to 3.6m
