SECO Adjustable Tilt Monument Adapter - 35mm 5/8 x 11" Male
$650.00
In Stock
Professional Stainless Steel CORS monument adapter.
- Diameter 8.19 cm (3.2")
- Height: 7.71cm (3.036")
- Includes a removable brass 5/8 x 11" male stud that is adjustable in azimuth and held in location by two set screws
- The adapters are leveled by three screws with a tilt range +/- 7°
- The height above the pivot point to the stud shoulder is 3.50cm (1.37")
- Height below the brass 5/8" stud to the shoulder is 1.18cm (0.463")
- The axis height is engraved on the outside of the monuments
- Weight: 2.8kg
Related Categories
Adapters
Brand: Seco |
Code: SEC2072-33
APN: 9319499197766 |
Supplier Code: 2072-33
