SECO Adjustable Tilt Monument Mount for 1.5" Pipe

Loading
  • SECO Adjustable Tilt Monument Mount for 1.5
  • SECO Adjustable Tilt Monument Mount for 1.5
  • SECO Adjustable Tilt Monument Mount for 1.5
$883.00 HURRY! Only 1 unit left

  • For 1.5-inch pipe with MPT 1-1/2 x 11-1/2 TPI
  • The adapters have 8.19 cm diameters and overall heights of 7.71 cm
  • Includes a removable brass 5/8 x 11 male stud that is adjustable in azimuth and held in location by two set screws
  • Leveled by three screws with a tilt range +/- 7°
  • The height above the pivot point to the stud shoulder is 3.50 cm
  • The height below the brass 5/8 stud to the shoulder is 1.18 cm
  • The axis height is engraved on the outside of the monuments
  • Weighs 2.50 kg

Brand: Seco | Code: SEC2072-30
APN: 9319499230272 | Supplier Code: 2072-30
Supplier Description: Adjustable Tilt Monument Mount

Brand: Seco | Code: SEC2072-30
APN: 9319499230272 | Supplier Code: 2072-30
Supplier Description: Adjustable Tilt Monument Mount
