Leica AR10 GNSS Reference Station Antenna

The AR10 is the ideal antenna for a wide range of high accuracy permanent and mobile base station applications. It offers near choke-ring performance but without the weight, size and cost. Provides exceptional signal tracking, phase centre accuracy and multipath suppression.

The AR10 is the ideal antenna for a wide range of high accuracy permanent and mobile base station applications. Using state-of-the-art technology it offers near choke-ring level performance but without the weight, size and cost. An all new antenna design, together with a large ground plane and integrated radome, ensures that the AR10 provides exceptional signal tracking, phase centre accuracy and multipath suppression.

Brochures
	LG773758 Leica AR10 - Brochure

Related Categories

Brand: Leica Geosystems | Code: LG773758
APN: 9319499607241 | Supplier Code: 773758

At a glance

Related Categories

Features

Future Proof
With emerging satellite systems close on the horizon, such as the European Galileo system and the Chinese Compass (Beidou 2) system, it is more important than ever before to have a true GNSS antenna. In line with Leica Geosystems future proof philosophy, the AR10 has been designed for all existing and currently planned signals of the GPS, GLONASS, Galileo and Compass global navigation satellite systems and the SBAS, QZSS, Gagan, OmniSTAR and other L-band augmentation systems.ﾠ

Integrated Radome
Thanks to the integrated radome, the AR10 prevents build up of snow which could otherwise degrade signal quality.The non-spherical radome is designed for optimal signal quality and has the added benefit of discouraging birds from perching on the antenna, a common source of signal attenuation with rounded radomes. The aerodynamic shape of the antenna reduces wind loading and together with the light weight ensures that the AR10 can be used with a variety of antenna masts or as a field or campaign base on a tripod. Constructed using a robust and UV resistant enclosure the AR10 is made to withstand extreme temperature, humidity, dust, salt, solar radiation, pollution, shock and vibration.
Superior Performance
Designed from the ground up for wideband tracking, the new wideband antenna technology introduced in the AR10 provides superior low elevation tracking, multipath suppression and antenna phase centre accuracy across all frequency bands. An all new low noise amplifier (LNA) is used to provide exceptional low measurement noise for superior measurement quality. The new LNA technology also has excellent out of band rejection, helping to significantly reduce potential interference due to jamming. The AR10 is suitable for use with antenna cable lengths up to 70 m without the need for an in-line amplifier.
