Leica Piper 100G Green Beam Pipe Laser Package

Loading
  • Leica Piper 100G Green Beam Pipe Laser Package
  • Leica Piper 100G Green Beam Pipe Laser Package
  • Leica Piper 100G Green Beam Pipe Laser Package
  • Leica Piper 100G Green Beam Pipe Laser Package
  • Leica Piper 100G Green Beam Pipe Laser Package
$6,600.00 HURRY! Only 1 unit left

The Leica Piper 100G green beam brings exceptional performance, accuracy and simplicity to sewer construction and pipe applications. The compact Piper fits inside a 100mm (4 inch) pipe, assuring easy and efficient setup even in the smallest inverts.

High application versatility

In the pipe, over the top or in the manhole, the Leica Piper always delivers outstanding performance.

  • In the pipe - Piper's self-centring, rubber tipped feet and robust, cast-aluminium housing assures the highest reliability in pipeline construction.
  • Over the top - In above-ground tasks, the optional scope and the mount kit provide user-friendly solution for simple setup and operation.
  • In the manhole - In manhole applications, Piper's unique design and wide stable base make it easy to set up even in the tightest inverts.
  • Piper is 100% waterproof (sealed to IP X8 protection standard) and has a positive pressure nitrogen seal to deliver the ultimate reliability.

Piper hits the target every time
Piper is ideal anywhere line and grade is required.

  • Large clear display for easy grade reading. Line position, battery status and  level indication.
  • Piper's bright, visible beam is focused to maintain its crisp, clear spot and size over long distances.
  • Automatic grade compensation easily identifies and corrects grade errors. Piper automatically self-levels over a full grade range and eliminates the need to tip the laser for steep slopes.

Increased productivity with smart features
Piper 100 provides pipe and sewer contractors with smart, user-friendly features for enhanced application performance.

  • Strobe Mode - its multi-functional remote control strobes the laser beam for increased visibility.
  • Top pivot point (Lighted Pivot Point)  and Battery Saving Mode.

Laser Beam Colour Green
Wave Length 520nm
Lasser Class 3R
Max average radiant power 4.8mW
Working range Up to 200m
Grade Range -10% to +25%
Self-levelling Range -15% to +30%
Line Movement 6m @ 30m
Battery Li-Ion, up to 40 hours
Charging Time 4 hours
Operating temperature -20°C to +50°C
Dimensions 96mm x 267mm
Weight 2.0Kg
Housing Cast aluminium
Wireless remote distance

Front 150m

Back 10m

Self levelling accuracy +/-1.5mm at 30m
Auto targeting No
Warranty 5 years



Datasheets
Leica Piper 100G Green Beam Pipe Laser Package - Datasheet

  • Leica Piper 100G Green Beam pipe laser
  • Rugged carrying case
  • Remote control
  • Target assembly
  • Li-ion rechargable battery
  • Battery charger with AC and 12V car adapter
  • Self-centering feet set (150mm / 6")
  • 5-year warranty

Brand: Leica Geosystems | Code: LG6016058
APN: 9319499202880 | Supplier Code: 6016058
Supplier Description: Piper 100G Green Pipe Laser

Brand: Leica Geosystems | Code: LG6016058
APN: 9319499202880 | Supplier Code: 6016058
Supplier Description: Piper 100G Green Pipe Laser

At a glance

The Leica Piper 100G green beam brings exceptional performance, accuracy and simplicity to sewer construction and pipe applications. The compact Piper fits inside a 100mm (4 inch) pipe, assuring easy and efficient setup even in the smallest inverts.
