The latest RIEGL VZ-600i is a 3D Laser Scanning System which combines an innovative new processing architecture, internet connectivity, and a suite of MEMS sensors with RIEGL’s latest Laser Scanning Engine technology.

High Productivity

Rapid scanning, on-board registration, high-speed processing

  • "One-Touch" Button Operation
  • Riegl VZ-i Project Map App for scan project monitoring
  • Concurrent scan and image data acquisition
  • Real-Time On-Board automatic registration
  • "One-Touch" Processing Wizard for automatic production of end deliverables

Ultimate Performance

High pulse repetition rate and scanning speed 30 seconds for a "Panorama_6mm" scan

  • Pulse Repetition rate up to 2.2 Mhz
  • Scan Speed up to 420 lines/sec
  • 30 sec scan time (6mm resolution @10m distance)
  • High speed data download of up to 500MB/s

Extreme Versatility

  • Suitable for various application
  • Indoor and outdoor 3D mapping
  • Short and long ranges
  • Lightweight (approx. 6kg / 13lbs)
  • Dual processor architecture for developing user-specific Python apps

Additional Mobility

  • Prepared for robotic operation integration (ROS driver available)
  • Option for kinematic laser scanning
  • can be used with the RIEGL VMR Robotic Rail Scanning System
  • Flexible mounting platform

Exceeding Your Expectations

RIEGL‘s latest generation of professional Terrestrial Laser Scanners stands out with extreme versatility, high productivity, ultimate performance and additional mobility – providing an excellent return on investment!

Main Features

  • Pulse
  • Broad range capability (0.5 m up to 1000 m)
  • 5 sec scan time for low resolution overview scans
  • 30 sec scan time for 6 mm resolution @ 10 m distance » 60 scan positions per hour (with image acquisition)
  • 3D position accuracy up to 3 mm @ 50 m
  • High laser pulse repetition rate of up to 2.2 MHz
  • Scan speed up to 420 lines/sec
  • Eye safe operation at Laser Class 1
  • Precise real-time onboard registration
  • Internal cameras & GNSS receiver
  • Weight 6 kg / 13 lbs
  • Prepared for mobile use

Main Applications

  • Civil Engineering
  • Archeology and Cultural Heritage Documentation
  • Tunnel Surveying
  • Forestry
  • Research
  • Monitoring
  • Mining
  • Long range scanning

Brochures
RI60600 RiPANO - Brochure
Datasheets
Riegl VZ-600i 3D Laser Scanner - Datasheet
Specifications
Riegl VZ-600i 3D Laser Scanner - Specifications

Related Categories Reality Capture 3D Laser Scanners

Brand: Riegl Scanner | Code: RI60600
APN: RI41600 |

Brand: Riegl Scanner | Code: RI60600
APN: RI41600 |
