Leica Rugby 610 Laser Level with Rod-Eye 160 Digital - Alkaline
Leica Rugby 610 rotating laser - One button simplicity
- Simple and reliable, one button laser where no mistakes are possible
- Superb performance with all Leica Rod Eye receivers – extend your working range using the Rod Eye 160 Digital laser receiver
- Alkaline batteries
Technical Data |
Leica Rugby 610 |
Functionality |
Self-levelling horizontal, one button laser |
Range (diameter) |
1,100 m |
Self-levelling accuracy (defined at 25°C) |
± 2.2 mm @ 30 m |
Self-levelling range |
± 5° |
H.I. elevation alert |
YES |
Rotation speeds |
10 rps |
Laser diode type / class |
635 nm / Class 1 |
Dimensions (HxWxD) |
212 x 239 x 192 mm |
Batteries – alkaline |
Four D-cells |
Battery life – alkaline |
60 hours @ 20°C |
Weight with batteries |
2.4 kg |
Protection class (splash water / dust proof) |
IP67 |
Operating temperature range |
-10° to +50°C |
Brand: Leica Geosystems |
Code: LG6008616
APN: 9319499000134 |
Supplier Code: 6008616
Brand: Leica Geosystems |
Code: LG6008616
APN: 9319499000134 |
Supplier Code: 6008616
At a glance
