Leica NA532 Auto Level 32x Optical Zoom

Leica NA532 Auto Level 32x Optical Zoom

$550.00
  NO STOCK
  NO STOCK
PRODUCT ENQUIRY
Accurate measurements whatever the conditions.With the many obstructions and uneven surfaces, construction and building sites are full of levelling challenges.
Brand: Leica Geosystems    Code: LG840386
APN: 840386    Supplier Code:

Accurate measurements whatever the conditions.
With the many obstructions and uneven surfaces, construction and building sites are full of levelling challenges. To ensure the straightest and safest construction possible, you need a reliable instrument for all your levelling needs.

On your terms, on your site, Leica Geosystems is your trusted partner and the Leica NA524 provides you with reliable levels for accurate measurements and high quality results.

Features

  • Leica Geosystems is a pioneer in manufacturing levels and understands the needs of construction workers
  • Whatever your need, basic or more, Leica levels are your answer
  • With a unique design, these levels produce the highest quality results at the best price value
  • The unique design of the Leica NA500 Series reflects the high quality of technology featured inside each level
  • The Leica NA500 Series is ruggedly made to withstand the harshest elements
  • These levels, while highly accurate, provide quick and easy measurements
  • Unbeaten warranty and service offering
  • Leica Geosystems offers solutions for all your construction needs

Model

NA532

Standard deviation for 1 km double levelling (ISO17123-2)

1.6 mm

Telescope

Telescope image

upright

Magnification

32 x

Objective aperture

36 mm

Shortest target distance from instrument axis

< 1.0 m

Field of view at 100 m

< 2.1 m

Multiplication factor

100

Additive constant 0

0

Compensator

Working range

± 15’

Setting accuracy (standard deviation)

< 0.5’’

Sensitivity

8’ / 2 mm

Horizontal circle

Graduation

360°

Graduation interval

Weight (net)

1.5 kg

Operating temperature range

–20°C to +50°C



BROCHURES
Leica NA532 Auto Level 32x Optical Zoom - Brochure

Leica NA532 Automatic Level
Carry Case
User Manual

OVERVIEW

Accurate measurements whatever the conditions.
With the many obstructions and uneven surfaces, construction and building sites are full of levelling challenges. To ensure the straightest and safest construction possible, you need a reliable instrument for all your levelling needs.

On your terms, on your site, Leica Geosystems is your trusted partner and the Leica NA524 provides you with reliable levels for accurate measurements and high quality results.

FEATURES

Features

  • Leica Geosystems is a pioneer in manufacturing levels and understands the needs of construction workers
  • Whatever your need, basic or more, Leica levels are your answer
  • With a unique design, these levels produce the highest quality results at the best price value
  • The unique design of the Leica NA500 Series reflects the high quality of technology featured inside each level
  • The Leica NA500 Series is ruggedly made to withstand the harshest elements
  • These levels, while highly accurate, provide quick and easy measurements
  • Unbeaten warranty and service offering
  • Leica Geosystems offers solutions for all your construction needs

SPECIFICATIONS

Model

NA532

Standard deviation for 1 km double levelling (ISO17123-2)

1.6 mm

Telescope

Telescope image

upright

Magnification

32 x

Objective aperture

36 mm

Shortest target distance from instrument axis

< 1.0 m

Field of view at 100 m

< 2.1 m

Multiplication factor

100

Additive constant 0

0

Compensator

Working range

± 15’

Setting accuracy (standard deviation)

< 0.5’’

Sensitivity

8’ / 2 mm

Horizontal circle

Graduation

360°

Graduation interval

Weight (net)

1.5 kg

Operating temperature range

–20°C to +50°C



DOWNLOADS

BROCHURES
Leica NA532 Auto Level 32x Optical Zoom - Brochure

IN THE BOX

Leica NA532 Automatic Level
Carry Case
User Manual
