Leica iCON iCR80 Robotic Total Station
- Achieve more layout points all day every day.
- Robotic total station with tablet computer and software package.
Ability to layout complex designs
Laying out intricate designs is a difficult task construction crews face every day. Complex geometries must be simplified by converting them to lines and rectangles, which means the staked point will not represent the true design when brought to the field. With iCON build Layout Objects app integrated into the solution, users can lay out straight from 3D models by selecting an object, like a column or pipe, simply by tapping on it in the controller and benefit from the flexible creation of layout work packages for effective work progress management. With the Leica iCR80 construction total station complex architecture can finally be completed with ease.
Never loose lock
The iCR80 comes with automated aiming ATRplus, which intelligently and automatically detects environmental conditions, such as light, dust, rain and other site conditions. The new ATRplus, lock and re-lock technology speeds aiming and following of targets and delivers accurate measurements independent of user aiming or site conditions. Even when used on busy construction sites, the down time resulting from loss of lock is minimal, speeding up significantly your layout task.
Automated set up
Stay confident and efficient with the most reliable, simple and automated set up routine. With no user interaction required, the intelligent Setup Pilot app orientates the total station with only the push of a button, allowing you to begin work almost immediately. The successful setup completion is visually communicated, indicating layout can begin.
Lowest total cost of ownership
Leica Geosystems construction total stations have a high value, giving you the lowest total cost of ownership. Its resilient hardware allows for longevity and reliability, giving you many years of rough usage in the most demanding environments. Its level of quality ensures your data remains accurate, lowers downtime and keeps your productivity high in all environments and conditions. Invest in the smarter total station solution and reap massive long-term rewards.
|
Accuracy |
1”,2”,5” |
|
Range |
1.5m to 3500m |
|
Measurement Time |
Prism: 1mm + 1.5ppm |
|
Laser Dot Size @ 50m |
8mm x 20mm |
|
Measurement Technology |
Coaxial, visible red laser |
|
Target Aiming Type |
ATRplus |
|
Prism Search Type |
PowerSearch |
|
Field Software |
iCON Field Software running on the instrument |
|
Machine Control Capability |
Yes |
|
Processor |
Windows EC7 |
|
Operating Time |
6-8 Hours |
|
Data Storage |
2GB SD card 1GB or 8GB |
|
Weight |
5.3kg |
|
IP Rating |
IP55 |
| Datasheets | |
|---|---|
| Leica iCON iCR80 Robotic Total Station - Datasheet | Simulator |
| iCON Build simulator (105 MB .exe file) |
Leica Geosystems has developed an online learning platform for a wide range of products, to further educate customers to maximise the functionality of their instruments.
Our products have many excellent features which all contribute to increasing efficiency on site and the online learning platform assists you to gain the most value from your products.
The online learning courses are available to anyone who has a Leica Geosystems myWorld account, and an active Customer Care Package (CCP) for supported products.
Brand: Leica Geosystems |
Code: LG6013431
APN: 9319499064549 |
Supplier Code: 6013431 & 667301
Brand: Leica Geosystems |
Code: LG6013431
APN: 9319499064549 |
Supplier Code: 6013431 & 667301
At a glance
- Achieve more layout points all day every day.
- Robotic total station with tablet computer and software package.
Ability to layout complex designsLaying out intricate designs is a difficult task construction crews face every day. Complex geometries must be simplified by converting them to lines and rectangles, which means the staked point will not represent the true design when brought to the field. With iCON build Layout Objects app integrated into the solution, users can lay out straight from 3D models by selecting an object, like a column or pipe, simply by tapping on it in the controller and benefit from the flexible creation of layout work packages for effective work progress management. With the Leica iCR80 construction total station complex architecture can finally be completed with ease. |
|
|
|
Never loose lockThe iCR80 comes with automated aiming ATRplus, which intelligently and automatically detects environmental conditions, such as light, dust, rain and other site conditions. The new ATRplus, lock and re-lock technology speeds aiming and following of targets and delivers accurate measurements independent of user aiming or site conditions. Even when used on busy construction sites, the down time resulting from loss of lock is minimal, speeding up significantly your layout task. |
Automated set upStay confident and efficient with the most reliable, simple and automated set up routine. With no user interaction required, the intelligent Setup Pilot app orientates the total station with only the push of a button, allowing you to begin work almost immediately. The successful setup completion is visually communicated, indicating layout can begin. |
|
|
|
Lowest total cost of ownershipLeica Geosystems construction total stations have a high value, giving you the lowest total cost of ownership. Its resilient hardware allows for longevity and reliability, giving you many years of rough usage in the most demanding environments. Its level of quality ensures your data remains accurate, lowers downtime and keeps your productivity high in all environments and conditions. Invest in the smarter total station solution and reap massive long-term rewards. |
